Overview of Components

PCI_E1~5: PCIe Expansion Slots

Important

If you install a large and heavy graphics card, you need to use a tool such as MSI

Gaming Series Graphics Card Bolster to support its weight to prevent deformation of

the slot.

For a single PCIe x16 expansion card installation with optimum performance, using

the PCI_E1 slot is recommended.

When adding or removing expansion cards, always turn off the power supply and

unplug the power supply power cable from the power outlet. Read the expansion

card’s documentation to check for any necessary additional hardware or software

changes.

PCIe bandwidth table

Slot Single 2-Way

PCI_E1 (CPU)

@4.0 x16*

or @3.0 x16**

or @3.0 x8***

@4.0 x16*

or @3.0 x16**

or @3.0 x8***

PCI_E2 (PCH) 3.0 x1 ― 3.0 x1 ―

PCI_E3 (PCH)

4.0 x4*

or 3.0 x4**

***

@4.0 x4*

or @3.0 x4**

***

PCI_E4 (PCH) ― 3.0 x1 ― 3.0 x1

PCI_E5 (PCH) 3.0 x1 3.0 x1

(─: unavailable, @: graphics card, *: for 3rd Gen AMD Ryzen™, **: for 2nd Gen AMD

Ryzen™, ***: for Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with

Radeon™ Graphics)

Slots

3rd Gen AMD Ryzen™ 2nd Gen AMD Ryzen™

Ryzen™ with Radeon™

Vega Graphics and 2nd

Gen AMD Ryzen™ with

Radeon™ Graphics

PCI_E1

PCIe 4.0 x16 PCIe 3.0 x16 PCIe 3.0 x8

PCI_E2

PCIe 3.0 x1 PCIe 3.0 x1 PCIe 3.0 x1

PCI_E3

PCIe 4.0 x4 PCIe 3.0 x4 PCIe 3.0 x4

PCI_E4

PCIe 3.0 x1 PCIe 3.0 x1 PCIe 3.0 x1

PCI_E5

PCIe 3.0 x1 PCIe 3.0 x1 PCIe 3.0 x1
