- 6 -
FACTORY
BACKPLATE
REMOVING OF THE ORIGINAL PLASTIC HOLD-
DOWN AND THE FACTORY BACKPLATE
Using Philips-head screwdriver remove the four (4) UNC 6-32 screws securing
the original plastic hold-down clamps around the socket as shown on the
sketch. Remove the original backplate and the hold- down clamps.
UNC 6-32 SCREWS

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the MSI MPG X570S Carbon EK X and is the answer not in the manual?

MSI MPG X570S Carbon EK X Specifications

General IconGeneral
ChipsetAMD X570
CPU SocketAM4
Form FactorATX
Memory Slots4
Max Memory128 GB
SATA Ports6
LAN2.5G LAN
WiFiWi-Fi 6E
BluetoothBluetooth 5.2
AudioRealtek ALC4080 Codec
RGB SupportMystic Light RGB
M.2 Slots4
PCIe Slots2x PCIe 4.0 x16 (x16/x0 or x8/x8), 1x PCIe 4.0 x16 (x4 mode), 2x PCIe 4.0 x1
Water CoolingYes (EK water block included)
