15
Specifications
Continued from previous page
RAID
Intel® Z490 Chipset
∙ Supports RAID 0, RAID1, RAID 5 and RAID 10 for SATA
storage devices
∙ Supports RAID 0 and RAID 1 for M.2 PCIe storage devices
LAN 1x Realtek® RTL8125B-CG 2.5G LAN Controller
USB
∙ Intel® Z490 Chipset
▪ 1x USB 3.2 Gen 2 10Gbps Type-A port on the back
panel
▪ 7x USB 3.2 Gen 1 5Gbps (4 Type-A ports on the back
panel, 2 ports through the internal USB connector, 1
Type-C internal connector)
▪ 2x USB 2.0 ports on the back panel
▪ 4x USB 2.0 ports available through the internal USB
connectors, hub-GL850G
∙ ASMedia® ASM3241
▪ 1x USB 3.2 Gen 2x2 20Gbps Type-C port on the back
panel
Audio
1x Realtek® ALC1200-VD1 Codec
∙ 7.1-Channel High Definition Audio
∙ Supports S/PDIF output
Wireless/ Bluetooth
Intel® AX201
∙ MU-MIMO TX/RX, 2.4GHz/ 5GHz (160MHz) up to 2.4Gbps
∙ 802.11ac; WiFi 6 pre certified
∙ Bluetooth 5.1, FIPS, FISMA
∙ 1x M.2_3 Socket with E key (Wi-Fi mode)
Back Panel
Connectors
∙ 1x PS/2 keyboard/ mouse combo port
∙ 2x USB 2.0 ports
∙ 1x Display port
∙ 1x HDMI port
∙ 1x USB 3.2 Gen 2 10Gbps Type-A port
∙ 1x USB 3.2 Gen 2x2 20Gbps Type-C port
∙ 1x LAN (RJ45) port
∙ 4x USB 3.2 Gen 1 5Gbps Type-A ports
∙ 2x Wi-Fi antenna connectors
∙ 1x Optical S/PDIF OUT connector
∙ 5x audio jacks
Continued on next page
