Rear I/O Panel
Rear I/O Panel
Audio Ports

WiFi antenna
connector
PS/2
HDMI port
Displayport
USB 2.0
2.5Gbps LAN
USB 3.2 Gen 2 10Gbps

USB 3.2 Gen 1 5Gbps
USB 3.2 Gen 2x2 20Gbps

Audio Ports Configuration
Audio Ports
Channel
2 4 6 8
  
Rear Speaker Out   
 
    
Mic In
Blank: empty)
Link/ Activity LED
Status Description
Off No link
Yellow Linked
Blinking Data activity
Speed LED
Status Description
Off 10 Mbps connection
Green 100 Mbps / 1 Gbps connection
Orange 2.5 Gbps connection
LAN Port LED Status Table
