3
Specifications
Specifications
CPU
Supports 10th Gen Intel® Core™ and Pentium® Gold /
Celeron® processors for LGA 1200 socket*
* Please go to www.intel.com for more compatibility information.
* Onboard graphics output are disabled when using F SKU processors.
Chipset Intel® Z490 Chipset
Memory
∙ 4x DDR4 memory slots, support up to 128GB*
∙ Supports 1R 2133/2666/2933 MHz*
▪ 1DPC 1R Max speed up to 4800+ MHz
▪ 1DPC 2R Max speed up to 4266+ MHz
▪ 2DPC 1R Max speed up to 4400+ MHz
▪ 2DPC 2R Max speed up to 4000+ MHz
∙
∙
∙ Supports Intel® Extreme Memory Profile (XMP)
* Please refer www.msi.com for more information on compatible memory.
Expansion Slot
∙ 2x PCIe 3.0 x16 slots*, support x16/ x0 or x8/ x8 mode
∙ 2x PCIe 3.0 x1 slots
* Please refer to page 17 for details.
Multi-GPU
∙
∙
Onboard Graphics
∙ 1x HDMI port, supports a maximum resolution of
4096x2160 @30Hz
∙ 1x DisplayPort, supports a maximum resolution of
4096x2304 @60Hz
∙ Maximum shared memory is 1GB
Continued on next page
