MSI MPG Z790 CARBON WIFI User Manual

17
Continued from previous column
Wi-Fi & Bluetooth®
Intel® Wi-Fi 6E
 The Wireless module is pre-installed in the M.2 (Key-E)
slot
 Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz*(160MHz)
up to 2.4Gbps
 Supports 802.11 a/ b/ g/ n/ ac/ ax
 Supports Bluetooth® 5.3**, FIPS, FISMA
* Wi-Fi 6E 6GHz may depend on every country’s regulations and will be ready in
Windows 10 build 21H1 and Windows 11.
** Bluetooth 5.3 will be ready in Windows 10 build 21H1 and Windows 11.
Power Connectors
 1x 24-pin ATX main power connector
 2x 8-pin +12V power connectors
Internal USB
Connectors
 1x USB 3.2 Gen 2x2 20Gbps Type-C front panel port (From
Z790 chipset)
 1x USB 3.2 Gen 1 5Gbps connector (From Z790 chipset)
• Supports additional 2 USB 3.2 Gen 1 5Gbps ports
 2x USB 2.0 connectors (From Hub-GL850G)
• Supports additional 4 USB 2.0 ports
Fan Connectors
 1x 4-pin CPU fan connector
 1x 4-pin water-pump fan connector
 5x 4-pin system fan connectors
System Connectors
 1x Front panel audio connector
 2x System panel connectors
 1x Chassis Intrusion connector
 1x TPM module connector
 1x Tuning controller connector
 1x TBT connector (Supports RTD3)
Jumpers
 1x Clear CMOS jumper
 1x Safe Boot jumper
Continued on next column

MSI MPG Z790 CARBON WIFI Specifications

General

Processor socket	LGA 1700
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium Gold
Non-ECC	Yes
Memory channels	Dual-channel
Number of memory slots	4
Supported memory types	DDR5-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	4800, 5000, 5200, 5400, 5600, 5800, 6400, 6600, 6800, 7000, 7200, 7400, 7600 MHz
Supported memory clock speed (max)	7600 MHz
RAID levels	0, 1, 5, 10
Supported storage drive types	HDD & SSD
Number of storage drives supported	10
Supported storage drive interfaces	M.2, PCI Express
Parallel processing technology support	Not supported
Number of SATA II connectors	0
Number of SATA III connectors	6
USB 3.2 Gen 1 (3.1 Gen 1) connectors	2
USB 3.2 Gen 2 (3.1 Gen 2) connectors	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.3
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Ethernet interface type	2.5 Gigabit Ethernet
Component for	PC
Product color	Black
Motherboard chipset	Intel Z790
Audio output channels	7.1 channels
Motherboard form factor	ATX
Windows operating systems supported	Windows 10 x64, Windows 11 x64
BIOS type	UEFI AMI
BIOS memory size	256 Mbit
Cables included	SATA
Number of M.2 (M) slots	5

Weight and Dimensions

Depth	243.84 mm
Width	304.8 mm
