MSI MPG Z790 CARBON WIFI

34
Installing M.2 module into M2_2 slot
1. Loosen the screws of M2_1 SHIELD FROZR heatsink and remove the heatsink.
11
11
2. Remove the protective films from the M.2 thermal pads on the M.2 plate.
22
3. Remove or exchange the screws according to your SSD length. Skip this step, if you
install 2280 SSD.
33
33
22110 SSD
2260 SSD
