User’s Guide
5. Card Layout
1-5
1. J1 VGA Connector
2. U1 3DLABs Permedia 2
3. Y1 Crystal 14.31818MHz
4. U5~U12 256kx32SGRAM
5. U2 VGA BIOS
JP2
Y1
U1
U2
U5
U6
U8
U10
U12
U7
U9
U11
J1
Jumper Setting: JP2
Short 1-2 VGA Enable
Short 2-3 VGA Disable
