CHAPTER 2 HARDWARE INSTALLATION
2-24
2.5-1 Power Switch
Connect to a 2-pin push button switch. This switch had the same feature
with JRMS1.
2.5-2 Reset Switch
Reset switch is used to reboot the system rather than turning the power ON/
OFF. Avoid rebooting while the HDD LED is lit. You can connect the Reset
switch from the system case to this pin.
2.5-3 Keylock
Keylock allows you to disable the keyboard for security purposes. You can
connect the keylock to this pin.
2.5-4 Power LED
The Power LED is always lit while the system power is on. You can connect
the Power LED from the system case to this pin.
2.5-6 Speaker
Speaker from the system case is connected to this pin.
If on-board speaker is available:
Short pin 14-15: On-board speaker Enabled.
Open pin 14-15: On-board speaker Disabled.
2.5-7 HDD LED
HDD LED shows the activity of a hard disk drive. Avoid turning the power
off while the HDD led is lit. You can connect the HDD LED from the system
case to this pin.
To Next Page
