CHAPTER 2 HARDWARE INSTALLATION
2-42
2.23 SCSI Connectors
The mainboard provides three SCSI connector.
On-board 16-Bit Ultra Wide SCSI
CH1 connector
On-board 16-Bit Ultra Wide SCSI
CH2 connector
On-board 8-Bit Ultra SCSI
CH2 connector
