BIOS Flash Jumper: J17BIOS Flash Jumper: J17
BIOS Flash Jumper: J17BIOS Flash Jumper: J17
BIOS Flash Jumper: J17
This jumper is used to lock/unlock BIOS Flash. This jumper should be
unlock when flashing/programming the BIOS.
J17
BIOS Flash
Locked
BIOS Flash
Unlocked
