Quick Components Guide
Component Function Reference
ATX Power Supply/JPW1 ATX power connectors See p. 2-7
JKBMS1 Mouse/keyboard connector See p. 2-8
USB Connectors Connecting to USB devices See p. 2-9
COM A & COM B Serial port connector See p. 2-10
VGA DB 15 Pin Connecting to VGA monitor See p. 2-10
LAN Jack (optional) Connecting to LAN devices See p. 2-11
LPT1 Parallel port connector See p. 2-12
FDD1 Floppy disk drive connector See p. 2-13
J8 Chassis intrusion switch connector See p. 2-13
IDE1~ IDE2 Hard disk connectors See p. 2-14
JCD1/JAUX1/JMD1 CD/AUX/Modem-in connectors See p. 2-15
CPUFA/SYSFA Fan power connectors See p. 2-16
JFP1/JFP2 Front panel connectors See p. 2-17
JAUD Front panel audio connector See p. 2-18
JUSB1/JUSB2 USB front connector See p. 2-19
JIR1 IrDA infrared module connector See p. 2-20
JBAT1 Clear CMOS jumper See p. 2-21
AGP Slot Connecting to AGP cards See p. 2-22
PCI Slots Connecting to expansion cards See p. 2-22
CNR Slot Connecting to expansion cards See p. 2-22
