MSI MS-7360 - System Specifications; Processor, FSB, and Chipset; Memory, LAN, and IEEE 1394; Audio, IDE, SATA, and RAID

En-2
MS-7360 Mainboard
Specifications
Processor Support
- Intel
®
Core 2 Extreme, Core 2 Quad, Core 2 Duo, Pentium and
Celeron in the LGA775 package
(For the latest information about CPU, please visit http://global.msi.
com.tw/index.php?func=cpuform)
Supported FSB
- 1333/ 1066/ 800/ 533 MHz
Chipset
- North Bridge: Intel
®
P35/ G33 (optional)
- South Bridge: Intel
®
ICH9/ ICH9R (optional)
Memory Support
- DDR2 667/ 800 SDRAM (240pin/ non-ECC)
- 4 DDR2 DIMM slots (8GB Max)
(For more information on compatible components, please visit http:/
/global.msi.com.tw/index.php?func=testreport)
LAN
- Supports 10/100/1000 Fast Ethernet by Realtek
®
RTL8111B
IEEE 1394
- Chip integrated by VIA VT 6308
- Transfer rate is up to 400Mbps
Audio
- Chip integrated by Realtek ALC888
- Up to 7.1 Channel audio-out
- Compliant with Azalia Spec
IDE
- 1 IDE port by Marvell 88SE6111
- Supports Ultra DMA 66/100/133, PIO & Bus Master operation
mode
SATA
- 4 SATA ports (SATA1~4) are controlled by ICH9
- 6 SATA ports (SATA1~6) are controlled by ICH9R
- SATA7 is controlled by Marvell 88SE6111 (optional)
- Supports storage and transfers up to 300 MB/s
RAID
- SATA1~6 support RAID 0/ 1/ 0+1/ 5 or JBOD mode (for ICH9R only)
