En-11
Installation Guide
English
Front USB Connector (Yellow)
This connector, compliant with Intel
®
I/O Connectivity Design Guide, is ideal for con-
necting high-speed USB interface peripherals such as USB HDD, digital cameras, MP3
players, printers, modems and the like.
Important
Note that the pins of VCC and GND must be connected correctly to avoid possible
damage.
10
Front Panel Audio Connector (Azalia Spec)
This connector allows you to connect the front panel audio and is compliant with Intel
®
Front Panel I/O Connectivity Design Guide.
12
USB 2.0 Bracket
(Optional)
S/PDIF-Out Connector
This connector is used to connect S/PDIF (Sony & Philips Digital Interconnect Format)
interface for digital audio transmission.
SPDIF Bracket (Optional)
11
USBOC
10
1
2
VCC
USB0-
USB0+
GND
Key (no pin)
VCC
USB1-
USB1+
GND
9
VCC
SPDIF_out
GND
1
2
9
10
M
I
C
_
L
M
I
C
_
R
L
I
N
E
o
u
t
_
R
F
r
o
n
t
_
J
D
L
I
N
E
o
u
t
_
L
G
r
o
u
n
d
P
r
e
s
e
n
c
e
#
M
I
C
_
J
D
N
C
(
N
o
p
i
n
)
L
I
N
E
o
u
t
_
J
D
