MSI MS-N0E1 User Manual

110W（MS-N0E1）Disassembly Guide
2、MB ASSY
2.7：Remove the 2 screws (M2*3mm) that stabilize
the USB Board.
Attention: the screw driver torque is 1.2-1.5Kgf-cm
Component P/N Qty
Screw
E43-1203003-H29
2
USB Board
607-N0E1A-01S
1
2.8：Remove the USB FFC.
2.9：Remove the GPS and Wlan antenna.
Wlan
GPS
