All specifications and informations are subject to change without notice.
-5-
V. Operation Menu (OSD) Function Descriptions
Note: The functions may be adjusted due to specific model or the upgrade of software version. The physical model shall govern.
In no-signal state, automatically power off after 1min standby
Activate FreeSync function, only AMD display card supported (the
support from the display is needed)
OD general mode, reducing motion vague (the support from the
display is needed)
OD top speed mode, reducing motion vague (the support from
the display is needed)
Slightly adjust green color temperature
100
0
50
100
0
50
50
R
50 50
G B
Input
DVI
HDMI
DisplayPort
Inactivate the timed power-off function
Restore to factory settings
Exit from this function
Standard
Movie
Eye Saver
RTS
FPS
Off
On
Off
On
Auto
169
43
None
Off
Normal
Extreme
Warm
Cool
User
Française Française
Deutsch Deutsch
Italiano Italiano
Español Español
한국어 한국어
Русский Русский
Português Português
日本語 日本語
繁體中文 繁體中文
English English
Off
On
Normal use mode
Application mode of seeing film
First person shooting game mode
Strategic game mode
Eye-protecting blue light filtered application mode
Activate dynamic contrast
Inactivate dynamic contrast
Inactivate FreeSync function
Automatic image scale adjustment
Adjust image to be wind screen
Adjust image to be 4:3
OD off mode (the support from the display is needed)
Set as cold color temperature
Set as warm color temperature
Adjust display bright
Adjust display contrast
DVI (digital) signal input
HDMI (digital) signal input
DisplayPort (digital) signal input
Inactivate sight bead function
Slightly adjust red color temperature
Slightly adjust blue color temperature
Off
On
Gamma
Adjust color tone brightness grey 1.8
Adjust color tone brightness grey 2.2
LED off
LED on
Off
On
LED
Mode
DCR
FreeSync
Aspect ratio
Crosshair
Response time
Brightness
Contrast
Color Temp.
Game
Setup
Language
Power Off
Reset
First level
menu item
Second level
menu item
Instructions
Third level
menu item
2.2
1.8
Transparency
5
0
2
All specifications and informations are subject to change without notice.
-4-
IV. User Setup
1. Schematic Diagram of Keys
M
E
1 2 3 4 5 6
2. Description of Keys' Functions
Note: The physical keys of the specific model shall govern.
LED
indicator
light
1.
2.
3.
4.
6.
5.
Pops up the menu/Backs to the previous menu (in case of main menu,
exits from the whole menu).
When the menu is activated, used as the left function selection key,
and decreases progressively the value of the progress bar; when the
menu is inactivated, used as the specified shortcut mode hot key (for
sighting device).
When the menu is activated, used as the right function selection key,
and increases progressively the value of the progress bar; when the
menu is inactivated, used as the specified shortcut mode hot key
(FPS/RTS mode).
If the menu is activated, chooses the corresponding function.
When no menu is open, press this key to switch to the desired signal
input source.
Power switch: Powers on/off the monitor.
Blue: in normal switch-on state; flickering in blue: in power-saving state.
M
E
Switch to red Crosshair mode
Switch to white Crosshair mode
Adjust transparency

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the MSI Optix AG32CQ and is the answer not in the manual?

MSI Optix AG32CQ Specifications

General IconGeneral
3DNo
Panel typeVA
Pixel pitch0.2724 x 0.2724 mm
Display surfaceMatt
Display diagonal31.5 \
Screen curvature1800 mm
Display technologyLED
Native aspect ratio16:9
Vertical scan range48 - 144 Hz
Horizontal scan range56 - 214.56 kHz
NTSC coverage (typical)85 %
Screen curvature rating1800R
Viewable size, vertical393.696 mm
sRGB coverage (typical)110 %
Contrast ratio (dynamic)100000000:1
Contrast ratio (typical)3000:1
Display number of colors16.78 million colors
Viewable size, horizontal697.344 mm
Display brightness (typical)250 cd/m²
Supported graphics resolutions2560 x 1440
DisplayPort version1.2
VGA (D-Sub) ports quantity0
Cable lock slot-
Tilt angle range-5 - 20 °
Panel mounting interface100 x 100 mm
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)- W
Power consumption (typical)60 W
Package weight8940 g
Product colorBlack
Market positioningGaming
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)209 mm
Width (with stand)723 mm
Height (with stand)512 mm
Weight (with stand)6630 g
