MSI PH61A-P35 (B3)

Hardware Setup
MS-7732
Chapter 2
2-11
Hardware Setup
MS-7732
Chapter 2
Back Panel
Mouse/Keyboard
The standard PS/2
®
mouse/keyboard DIN connector s for a PS/2
®
mouse/keyboard.
USB 2.0 Port
The USB 2.0 port s for attachng USB devces such as keyboard, mouse, or other USB-
compatble devces.
USB 3.0 Port (optonal)
USB 3.0 port s backward-compatble wth USB 2.0 devces. Supports data transfer rate
up to 5 Gbt/s (SuperSpeed).
Important
If you want to use a USB 3.0 devce, you must use the USB 3.0 cable to connect to the
USB 3.0 port.
VGA Port
The DB15-pn female connector s provded for montor.
DVI-D Port (optonal)
The DVI-D (Dgtal Vsual Interface - Dgtal) connector allows you to connect a LCD
montor. It provdes a hgh-speed dgtal nterconnecton between the computer and ts
dsplay devce. To connect an LCD montor, smply plug your montor cable nto the DVI
-D connector, and make sure that the other end of the cable s properly connected to
your montor (refer to your montor manual for more nformaton.)
Important
The VGA and DVI-D dsplay nterfaces on the manboard are desgned to serve as IGP
(Integrated Graphcs Processor) used. If you nstalled a processor wthout ntegrated
graphcs chp, these dsplay ports wll have no e󰘯ect.
▶
▶
▶
▶
▶
Lne-In
Lne-Out
Mc
VGA Port
USB 3.0 Port (PH61A-P35 (B3))
or USB 2.0 Port (PH61-P33 (B3))
DVI-D Port
RS-Out
CS-Out
SS-Out
Mouse
USB 2.0 Port
USB 2.0 Port
LAN
(optonal)
Keyboard
(optonal)
(optonal)
