MSI PRO MP243 User Manual

15
OSD Menus
1st Level Menu 2nd Level Menu Description
HDMI™ CEC OFF ∙ HDMI™ CEC (Consumer Electronics
Control) supports Sony PlayStation®,
Nintendo® Switch™, Xbox Series X|S
consoles and various audio-visual devices
that are CEC-capable.
∙ If HDMI™ CEC is set to ON:
• The monitor will automatically power on
when the CEC device is turned on.
• The CEC device will enter power saving
mode when the monitor is turned off.
• When Sony PlayStation®, Nintendo®
Switch™, or Xbox Series X|S console is
connected, Mode will be automatically
set to Eco mode (Default) and can be
adjusted to users’ preferred modes
later.
ON
Info. On Screen OFF ∙ The information of the monitor status will
be shown on the right side of the screen.
∙ Users can enable or disable the Info. On
Screen.
ON
Audio Volume 0-100 ∙ Users can adjust Audio Volume in any
mode.
Reset YES ∙ Users can Reset and restore settings to
original OSD Default in any mode.
NO

MSI PRO MP243 Specifications

General

Color depth	8 bit
Color gamut	99 %
Pixel pitch	0.2745 x 0.2745 mm
Aspect ratio	16:9
Screen shape	Flat
Display diagonal	23.8 \
Display technology	LCD
Maximum refresh rate	75 Hz
Viewable size, vertical	296.46 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Viewable size, horizontal	527.04 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDMI version	1.4
Microphone in	Yes
Headphone outputs	1
DisplayPort version	1.2a
VGA (D-Sub) ports quantity	0
Input current	2.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	- W
Package weight	4150 g
Tilt angle range	-5 - 20 °
Cable lock slot type	Kensington
Panel mounting interface	75 x 75 mm
Front bezel color	Black
Market positioning	Home
RMS rated power	4 W
Number of speakers	2

Weight and Dimensions

Depth (with stand)	182.16 mm
Width (with stand)	541.93 mm
Height (with stand)	421.79 mm
Weight (with stand)	2950 g
