MSI PRO MP243 User Manual

8
Getting Started
Connecting the Monitor to PC
1. Turn off your computer.
2. Connect the video cable from the monitor to your computer.
3. Assemble the external power supply & power cord. (Figure A)
4. Connect the external power supply to the monitor power jack. (Figure B)
5. Plug the power cord into the electrical outlet. (Figure C)
6. Turn on the monitor. (Figure D)
7. Power on the computer and the monitor will auto detect the signal source.
A
B
C
D

MSI PRO MP243 Specifications

General

Color depth	8 bit
Color gamut	99 %
Pixel pitch	0.2745 x 0.2745 mm
Aspect ratio	16:9
Screen shape	Flat
Display diagonal	23.8 \
Display technology	LCD
Maximum refresh rate	75 Hz
Viewable size, vertical	296.46 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Viewable size, horizontal	527.04 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDMI version	1.4
Microphone in	Yes
Headphone outputs	1
DisplayPort version	1.2a
VGA (D-Sub) ports quantity	0
Input current	2.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	- W
Package weight	4150 g
Tilt angle range	-5 - 20 °
Cable lock slot type	Kensington
Panel mounting interface	75 x 75 mm
Front bezel color	Black
Market positioning	Home
RMS rated power	4 W
Number of speakers	2

Weight and Dimensions

Depth (with stand)	182.16 mm
Width (with stand)	541.93 mm
Height (with stand)	421.79 mm
Weight (with stand)	2950 g
