16
Specifications
Specifications
Model
PRO MP243
PRO MP243W
PRO MP273
PRO MP273W
Size 23.8 inch 27 inch
Curvature Flat
Panel Type IPS
Resolution 1920 x 1080
Aspect Ratio 16:9
Brightness (nits) 250 (typ.)
Contrast Ratio 1000:1
Refresh Rate 75Hz
Response Time 5ms (GtG)
I/O
Power Jack x1
DisplayPort x1
HDMI™ Connector x1
Headphone Jack x1
View Angles 178°(H) , 178°(V)
DCI-P3*/ sRGB 77% / 97% 86% / 108%
Surface Treatment Anti-glare
Display Colors 16.7M (8 bit)
Speaker 2W x2
Monitor Power Options
12V 2.5A
External Power Supply Model: ADS-40NP-12-1 12030E
Power Input 100~240Vac, 50~60Hz, 1.0A Max
Power Output
12V 2.5A
Adjustment (Tilt) -5° ~ 20°
Adjustment (Height)
Adjustment (Swivel)

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the MSI PRO MP243 and is the answer not in the manual?

MSI PRO MP243 Specifications

General IconGeneral
Color depth8 bit
Color gamut99 %
Pixel pitch0.2745 x 0.2745 mm
Aspect ratio16:9
Screen shapeFlat
Display diagonal23.8 \
Display technologyLCD
Maximum refresh rate75 Hz
Viewable size, vertical296.46 mm
Contrast ratio (typical)1000:1
Display number of colors16.7 million colors
Viewable size, horizontal527.04 mm
Display brightness (typical)250 cd/m²
Supported graphics resolutions1920 x 1080 (HD 1080)
HDMI version1.4
Microphone inYes
Headphone outputs1
DisplayPort version1.2a
VGA (D-Sub) ports quantity0
Input current2.5 A
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)- W
Package weight4150 g
Tilt angle range-5 - 20 °
Cable lock slot typeKensington
Panel mounting interface75 x 75 mm
Front bezel colorBlack
Market positioningHome
RMS rated power4 W
Number of speakers2
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)182.16 mm
Width (with stand)541.93 mm
Height (with stand)421.79 mm
Weight (with stand)2950 g
