MSI PRO MP243 User Manual

14
OSD Menus
Setting
1st Level Menu 2nd Level Menu Description
Language 繁體中文 ∙ Users have to press the E Button to
confirm and apply the Language setting.
∙ Language is an independent setting.
Users’ own language setting will override
the factory default. When users set Reset
to Yes, Language will not be changed.
English
Français
Deutsch
Italiano
Español
한국어
日本語
Русский
Português
简体中文
Bahasa Indonesia
Türkçe
(More languages
coming soon)
Transparency 0~5 ∙ Users can adjust Transparency in any
mode.
OSD Time Out 5~30s ∙ Users can adjust OSD Time Out in any
mode.
Power Button OFF ∙ When set to OFF, users can press the
power button to turn off the monitor.
Standby ∙ When set to Standby, users can press the
power button to turn off the panel and
backlight.

MSI PRO MP243 Specifications

General

Color depth	8 bit
Color gamut	99 %
Pixel pitch	0.2745 x 0.2745 mm
Aspect ratio	16:9
Screen shape	Flat
Display diagonal	23.8 \
Display technology	LCD
Maximum refresh rate	75 Hz
Viewable size, vertical	296.46 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Viewable size, horizontal	527.04 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDMI version	1.4
Microphone in	Yes
Headphone outputs	1
DisplayPort version	1.2a
VGA (D-Sub) ports quantity	0
Input current	2.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	- W
Package weight	4150 g
Tilt angle range	-5 - 20 °
Cable lock slot type	Kensington
Panel mounting interface	75 x 75 mm
Front bezel color	Black
Market positioning	Home
RMS rated power	4 W
Number of speakers	2

Weight and Dimensions

Depth (with stand)	182.16 mm
Width (with stand)	541.93 mm
Height (with stand)	421.79 mm
Weight (with stand)	2950 g
