MSI PRO Z790-P WIFI DDR4

38
󽂎󻃏󼳚󽂪󻙖󻗞󼳖󺼗󼼢
󼕦󼳖󺼗󼼢󻝮󻺞󼒛󽍊󼏞󼐧󻽊󼕪󽂎󻃏󼳚󽂪󻙖󻗞󻢚󻊺󼔶󼏢󺪢󽍒󼀊󼕺󼂧󻂺󻃖
1
2 6
5
󽌲 󼃒󽐪󼕦󻝶 󽌲 󼃒󽐪󼕦󻝶
1 No Pin 2 NC
3 MCU_SMB_SCL_M 4 MCU_SMB_SDA_M
5 VCC5 6 Ground
󼅞󻅆󻫮󽂪󼮆󺧲󼱦󻋎󼳖󺼗󼼢
󼕦󼳖󺼗󼼢󻝮󻺞󼒛󽍊󼏞󻼒󼻏󼏂󻌢󻕮󼮆󺧲󼅞󻅆󻫮󽂪󼱦󻋎󼐲󼏢󺪢󽍒󼀊󼕺󼂧󻂺󻃖
󽌲 󼃒󽐪󼕦󻝶 󽌲 󼃒󽐪󼕦󻝶
1 TBT_Force_PWR 2 TBT_S0IX_Entry_REQ
3 TBT_CIO_Plug_Event# 4 TBT_S0IX_Entry_ACK
5 SLP_S3#_TBT 6 TBT_PSON_Override_N
7 SLP_S5#_TBT 8 Net Name
9 Ground 10 SMBCLK_VSB
11 DG_PEWake 12 SMBDATA_VSB
13 TBT_RTD3_PWR_EN 14 Ground
15 TBT_Card_DET_R# 16 PD_IRQ#
1
2 16
15
