3. Move the EZ M.2 Clip according to your SSD length (for 2260/ 2242 SSD). Skip this
step, if you install 2280/ 22110 SSD.
4. Insert your M.2 SSD into the M.2 slot at a 30-degree angle.
5. Rotate the EZ M.2 Clip to fix the M.2 SSD.
30º30º
33
33
55
44
6. Put the M.2 SHIELD FROZR heatsink back in place and secure it.
66
66
