MSI PRO Z790-P WIFI DDR4 - Motherboard Block Diagram

i
Block Diagram
PCIe 5.0x16 PCI_E1
DDR4
DIMM A1/A2
DIMM B1/B2
GEN4 x4 M.2_1
(PCIe Only)
GEN4 x4 M.2_2 / M.2_3 / M.2_4
USB3.2 Gen2 10Gbps
(Rear Type-A)
Intel 2.5Gbps LAN
SATA_1_2_3_4_5_6
WiFi 6E
PCH
HD Audio
ALC897
CPU
DMI x8
PCIe 5.0 X16
USB3.2 Gen1 5Gbps
(Front Type-A)
USB3.2 Gen2 10Gbps
(Front Type-C)
USB3.2 Gen2x2 20Gbps
(Type-C)
GL850
USB2.0
(Front Type-A)
SPI
USB3.2 Gen1 5Gbps
(Rear Type-A)
PCIe 4.0 X4
PCIe 4.0x4 PCI_E3
PCIe 3.0 X1
PCIe 3.0x1 PCI_E2, PCI_E4
USB2.0
(Rear Type-A)
GL850
HDMI 2.1
(4K@60Hz)
DP 1.4
(4K@60Hz)
(Only PRO Z790-P WIFI DDR
PRO Z790-P WIFI DDR4/PRO Z790-P DDR4
