MSI Stealth 17 Studio Series User Manual

2-6 2-7
Right Side View
1. USB 3.2 Gen 2 Port (Type-C) (with DisplayPort function)
USB 3.2 Gen 2, the SuperSpeed USB 10Gbps, supports high-speed data transfer for
connected devices, such as storage devices, hard drives, or video cameras.
The slim and sleek USB Type-C connector offers reversible plug orientation, and
supports 5V/3A portable charging power when AC power is connected. However,
the maximum portable charging power limitation may up to 5V/1.5A while battery DC
power is connected.
2. Ventilator
The ventilator is designed to cool the system. DO NOT block the ventilator for air
circulation.
3. Card Reader
The built-in card reader supports various types of memory cards. Check the
Specifications for details.
4. Thunderbolt (Type-C) combo ports
• Thunderbolt™ 4, optionally supports USB4, PCIe, HDMI™, DisplayPort
connection; 8K display monitor output; up to 40Gbps transfer rate.
• Supports Power Delivery function with variable up to 100W power input and
maximum 9V/3A or 5V/3A power output when AC or DC power is connected. )
• Supports using a power bank to supply power to the notebook and charge the
battery pack. Make sure the charging power output of the power bank meets the
minimum requirements of the notebook.

MSI Stealth 17 Studio Series Specifications

General

Operating System	Windows 11 Pro
Weight	2.8 kg
Processor	13th Gen Intel Core i9-13900H
Graphics	NVIDIA GeForce RTX 4090
Memory	Up to 64GB DDR5
Storage	Up to 2TB NVMe SSD
Battery	99.9Whr
Keyboard	Per-Key RGB Backlight Keyboard
Audio	2x 2W speakers, Nahimic 3 audio enhancer
Webcam	FHD Type (30fps@1080p)
LAN	2.5G LAN
Wireless	Wi-Fi 6E, Bluetooth 5.3
Ports	1x RJ45
Display	17.3" UHD (3840x2160), 144 Hz Refresh Rate, MiniLED, IPS-Level Panel, 100% DCI-P3, HDR 1000 17.3" QHD (2560x1440), 240 Hz Refresh Rate, IPS-Level Panel, 100% DCI-P3
