MS-7760 Manboard
Back Panel Quck Gude
Mouse/Keyboard
A combnaton PS/2
®
mouse/keyboard DIN connector for a PS/2
®
mouse/keyboard.
Clear CMOS Button
There s CMOS RAM present on board that s powered by an external battery to store
system con󰘰guraton data. Usng CMOS RAM, the system can automatcally boot nto
the operatng system (OS) every tme t s turned on. If you wsh to clear the system
con󰘰guraton, press the button to clear the data.
Coaxal S/PDIF-Out
Ths S/PDIF (Sony & Phlps Dgtal Interconnect Format) connector s provded for
dgtal audo transmsson to external speakers through a coaxal cable.
Optcal S/PDIF-Out
Ths S/PDIF (Sony & Phlps Dgtal Interconnect Format) connector s provded for
dgtal audo transmsson to external speakers through an optcal 󰘰ber cable.
IEEE 1394 Port
The IEEE 1394 port on the I/O panel provdes connecton to IEEE 1394-compatble
devces.
USB 2.0 Port
The USB 2.0 port s for attachng USB 2.0 devces such as keyboard, mouse, or other
USB 2.0-compatble devces.
▶
▶
▶
▶
▶
▶
Lne-In
Lne-Out
Mc
RS-Out
CS-Out
SS-Out
USB 2.0 PortUSB 2.0 Port USB 3.0 Port
LAN
Mouse/ Keyboard
Coaxal
S/PDIF-Out
Clear CMOS button
Optcal
S/PDIF-Out
USB 2.0 Port
IEEE 1394 Port
