MSI X79A-GD65 8D - LED Status Indicators (Continued); CPU Phase LED Explanations; Memory and DrMOS LED Explanations; HDD and DIMM Warning LED Explanations

En-32
MS-7760 Manboard
CPU_PHASE
These LEDs wll change accordng to CPU loadng. The hgher the power phase number,
the more relable the power 󰘱ow to the processor.
CPU_SA_PHASE
These LEDs ndcate the current CPU System Agent power phase mode.
CPU_IO_PHASE
These LEDs ndcate the current CPU I/O power phase mode.
DrMOS_ALARM
Ths LED wll lght when DrMOS overheat.
DDR_PHASE
These LEDs ndcate the current memory power phase mode.
HDD_LED
Ths LED wll 󰘱ash whenever there's a dsk actvty.
CHB/ CHD_DIMM_WARNING
These LEDs wll lght when the nstalled memores n channel B (DIMM3/ DIMM4) and
channel D (DIMM7/ DIMM8) do not meet the manboard desgn.
