En-40
MS-7760 Manboard
tWRDRDD
Wrte-Read D󰘯erent Ranks same or D󰘯erent DIMM.
tRWSR
Read-Wrte Same Rank.
Spread Spectrum
Ths functon reduces the EMI (Electromagnetc Interference) generated by modulatng
clock generator pulses.
Important
If you do not have any EMI problem, leave the settng at [Dsabled] for optmal system
stablty and performance. But f you are plagued by EMI, select the value of Spread
Spectrum for EMI reducton.
The greater the Spread Spectrum value s, the greater the EMI s reduced, and the
system wll become less stable. For the most sutable Spread Spectrum value, please
consult your local EMI regulaton.
Remember to dsable Spread Spectrum f you are overclockng because even a slght
jtter can ntroduce a temporary boost n clock speed whch may just cause your
overclocked processor to lock up.
Vdroop Control
Load lne droop controls the stream of current to the CPU.
[Auto] Automatcally sets values for maxmum stablty.
[Low VDroop] Provdes less 󰘱uctuaton (better for overclockng).
CPU Core Voltage/ System Agent Voltage (SA)/ CPU I/O Voltage/ CPU PLL Voltage/
DDR CH_A/B Voltage/ DDR CH_C/D Voltage/ DDR CH_A CA Vref Voltage/ DDR CH_B
CA Vref Voltage/ DDR CH_C CA Vref Voltage/ DDR CH_D CA Vref Voltage/ DDR
CH_A DQ Vref Voltage/ DDR CH_B DQ Vref Voltage/ DDR CH_C DQ Vref Voltage/
DDR CH_D DQ Vref Voltage/ PCH 1.1 Voltage/ PCH 1.5 Voltage.
These tems are used to adjust the voltage of CPU, Memory and chpset.
Current CPU Core Voltage/ Current SA Voltage/ Current DDR CH_A/B Voltage/
Current DDR CH_C/D Voltage
These tems show current CPU/ DRAM voltage. Read-only.
Overclockng Pro󰘰les
Press <Enter> to enter the sub-menu.
Overclockng Pro󰘰le 1/ 2/ 3/ 4/ 5/ 6
Press <Enter> to enter the sub-menu.
Set Name for Overclockng Pro󰘰le 1/ 2/ 3/ 4/ 5/ 6
Gve a name by typng n ths tem.
Save Overclockng Pro󰘰le 1/ 2/ 3/ 4/ 5/ 6
Save the current overclockng settngs to ROM for selected pro󰘰le.
Load/ Clear Overclockng Pro󰘰le 1/ 2/ 3/ 4/ 5/ 6
Load/ Clear the stored pro󰘰le settngs from ROM.
▶
▶
▶
•
•
•
▶
▶
▶
▶
▶
▶
▶
▶
