MSI X99A SLI PLUS - JAUD1: Front Panel Audio Connector; JTPM1: TPM Module Connector

Chapter 1
1-29
Getting Started
JAUD1: Front Panel Audio Connector
This connector allows you to connect the front audio panel located on your computer
case. This connector is compliant with the Intel
®
Front Panel I/O Connectivity Design
Guide.
SATA3_ 4SATA9_ 10
SATA1_ 2SATA7_ 8
1.MIC L
3.MIC R
10.Head
Phone Detection
5.Head Phone
R
7.SENSE_SEN
D
9.Head Phone
L
8.No Pin
6.MIC Detection
4.NC
2
.Ground
JTPM1: TPM Module Connector
This connector connects to a TPM (Trusted Platform Module). Please refer to the TPM
security platform manual for more details and usages.
SATA3_ 4SATA9_ 10
SATA1_ 2SATA7_ 8
10.No
P
in
14.Ground
8.5V
P
ower
12.Ground
6.Serial
I
RQ
4.3.3V
P
ower
2.3V
S
t
andby
power
1.LP
C
Cloc
k
3.LP
C
R
eset
5.LPC a
ddress
&
d
at
a
p
in0
7.LP
C a
ddress
&
data p
in1
9.LP
C a
ddres
s
& d
at
a
p
in2
11
.LPC
a
ddres
s
&
d
at
a p
in3
13.LPC
F
rame
