Specifications
Specifications
CPU
y Supports New Intel
®
Core™ i7 Processor Extreme Edition
for LGA2011-3 Socket
y Supports Intel
®
Turbo Boost Max Technology 3.0*
* This function will be supported depend on the CPU.
Chipset Intel
®
X99 Chipset
Memory
y 8x DDR4 memory slots, support up to 128GB*
 Supports DDR4 3466(OC) /3400(OC)/ 3333(OC)/ 3200(OC)/
3000(OC)/ 2933(OC)/ 2800(OC) / 2666(OC)/ 2600(OC)/
2400/ 2200(OC)/ 2133 MHz
y Quad channel memory architecture
y Supports non-ECC, un-buffered memory
y Supports Intel
®
Extreme Memory Profile (XMP)
y Supports RDIMM 1Rx8 memory module (Operates in non-
ECC mode)
* For the latest information about memory, please visit http://www.msi.com
Expansion Slots
y 5x PCIe 3.0 x16 slots (PCI_E1~PCI_E4 & PCI_E6*), support
up to 4-way mode.
 1-way mode: x16/x0/x0/x0/x0
 2-way mode: x16/x0/x0/x16/x0**, x16/x0/x0/x8/x0***
 3-way mode: x16/x0/x0/x16/x8** x8/x8/x0/x8/x0***
 4-way mode: x8/x8/x0/x16/x8**, x8/x8/x0/x8/x4***
y 1x PCIe 2.0 x1 slot (PCI_E5)
* PCI_E6 slot, U.2 port and M.2 PCIe 3.0 x4 share the same bandwidth. Please
refer to page 33 for PCIe bandwidth tables.
** For the CPU that supports 40 PCIe lanes
*** For the CPU that supports 28 PCIe lanes
Multi-GPU
y Supports 4-Way AMD
®
CrossFire™ Technology
y Supports 4-Way NVIDIA
®
SLI™ Technology
Storage
Intel
®
X99 Chipset
y 10x SATA 6Gb/s ports (2 ports from SATAe port)
y 1x M.2 slot (Key M)
 Supports up to PCIe 3.0 x4 and SATA 6Gb/s
 Supports 2242/ 2260 /2280/ 22110 storage devices
y 1x U.2 port*
 Supports PCIe 3.0 x4 NVMe storage
y 1x SATAe port (compatible with 2 SATA ports)**
 Supports up to PCIe 2.0x2
y Supports Intel
®
Smart Response Technology***
* The U.2 port will be unavailable when installing the PCIe device in PCI_E6
slot.
** SATAe port is backward compatible with SATA.
*** This function will be supported depend on the CPU.
Continued on next page
