Overview of Components
Component Contents
Port Name Port Type Page
CPUFAN1~2,SYSFAN1~3 Fan Connectors 42
CPU Socket LGA1151 CPU Socket 29
DIMM1~4 DIMM Slots 30
FLASHB1 BIOS FLASHBACK+ Button 43
HOT_KEY1 HOTKEY Main Switch 44
JAUD1 Front Audio Connector 41
JBAT1 Clear CMOS (Reset BIOS) Jumper 45
JCI1 Chassis Intrusion Connector 43
JFP1, JFP2 Front Panel Connectors 39
JPWR1~2 Power Connectors 38
JTPM1 TPM Module Connector 41
JUSB1~2 USB 2.0 Connectors 41
JUSB3~4 USB 3.1 Gen1 Connectors 39
M2_1~2 M.2 Slots 34
OC1 GAME BOOST Knob 37
PCI_E1~7 PCIe Expansion Slots 31
POWER1, RESET1 Power Button, Reset Button 38
SATA1~6 SATA 6Gb/s Connectors 33
SE1_43-SE2_65 SATAe Connectors 33
SLOW_1 Slow Mode Booting Switch 45

MSI Z170A GAMING M7 Specifications

General

Chipset	Intel Z170
CPU Socket	LGA 1151
Memory Slots	4 x DIMM
Maximum Memory	64GB
Form Factor	ATX
Audio	Realtek ALC1150
M.2 Slots	1
USB 3.1 Gen1 Ports	8
PCI Express x16 Slots	3
PCI Express x1 Slots	4
RAID Support	RAID 0, 1, 5, 10
Multi-GPU Support	AMD 3-Way CrossFire, NVIDIA 2-Way SLI
Storage Interface	6 x SATA 6Gb/s
USB Ports	8 x USB 3.1 Gen1
LAN	Killer E2400 Gigabit LAN Controller
