Overview of Components
Component Contents
Port Name Port Type Page
CPU_FAN1,SYS_FAN1~4,
PUMP_FAN1
Fan Connectors 35
CPU_PWR1, ATX_PWR1 Power Connectors 33
CPU Socket LGA1151 CPU Socket 26
DIMMA1, A2, B1, B2 DIMM Slots 27
JAUD1 Front Audio Connector 36
JBAT1 Clear CMOS (Reset BIOS) Jumper 37
JCI1 Chassis Intrusion Connector 36
JCOM1 Serial Port Connector 33
JFP1, JFP2 Front Panel Connectors 32
JLED1 RGB LED connector 38
JLPT1 Parallel Port Connector 38
JTPM1 TPM Module Connector 37
JUSB1~2 USB 2.0 Connectors 34
JUSB3~4 USB 3.1 Gen1 Connectors 34
M2_1~2 M.2 Slots (Key M) 30
PCI_E1~6 PCIe Expansion Slots 28
SATA1~6 SATA 6Gb/s Connectors 31
