Hardware Setup
Secure the lever near the hook end
under the retenton tab.
5. Make sure the four hooks are n proper
poston before you nstall the cooler.
Algn the holes on the manboard
wth the cooler. Push down the cooler
untl ts four clps get wedged nto the
holes of the manboard.
6.
Press the four hooks down to fasten
the cooler. Turn over the manboard
to con󰘰rm that the clp-ends are
correctly nserted.
7. Fnally, attach the CPU Fan cable
to the CPU fan connector on the
manboard.
8.
Important
Con󰘰rm f your CPU cooler s 󰘰rmly nstalled before turnng on your system.
Do not touch the CPU socket pns to avod damagng.
Whenever CPU s not nstalled, always protect your CPU socket pn wth the plastc
cap covered to avod damagng.
Please refer to the documentaton n the CPU cooler package for more detals about
the CPU cooler nstallaton.
Read the CPU status n BIOS.
•
•
•
•
•
