MSI Z68A-GD55 series User Manual

2-19
MS-7681
Chapter 2
Voltage Check Pont
Voltage Check Pont: FV1
Ths voltage check pont set s used to measure the current CPU/ CPU_VTT/ CPU_
GFX/ DDR/ PCH voltage.
CPU voltage: measure the current CPU voltage
wth CPU pont and GND pont by usng a mul-
tmeter.
CPU_VTT voltage: measure the current CPU_
VTT voltage wth CPU_VTT pont and GND
pont by usng a multmeter.
DDR voltage: measure the current DDR voltage
wth DDR pont and GND pont by usng a mul-
tmeter.
PCH voltage: measure the current PCH voltage
wth PCH pont and GND pont by usng a mul-
tmeter.
DDR
GND
GND
1
7
PCHCPU_GFX
CPU_VTT
CPU
GND
1
7
CPU
GND
1
7
CPU_VTT
GND
1
7
CPU_GFX
GND
1
7
DDR
GND
1
7
PCH
CPU_GFX voltage: measure the current CPU
Integrated Graphc voltage wth CPU_GFX pont
and GND pont by usng a multmeter.
