mspa DELIGHT BUBBLE Spa User Manual

2019-2020 Delight Service Manual
Visit our website at: www.the-mspa.com
- 13 -
25
The metal band
ψ30-45
2
SUS304
26
PE air pipe
1
PE
27
PE pressing buckle of air pipe
1
ABS
28
Motor outlet seal ring
1
silicon gel
45-55A
29-32,39,40-45
PTC heating element
1
AC230V/1500W
33
Screw M4*60
4
SPCC,
34
Water pipe
1
silicon gel
45-55A
35
The metal band
ψ
30-45
2
SUS304
36
Sealed ring for inlet/outlet
2
silicon gel
45-55A
37
PTC Support frame
2
PA66+30%GF
38
PTC fix mount
1
PA66+30%GF
46
Filter pump
1
AC12V/35W
47
Filter inlet pipe
1
PA66+30%GF
48
Upper nut
2
ABS
49
Under nut
2
ABS
50
PVC Inflatable mouth gasket
2
silicon gel
45-55A
51
Motor cabinet
1
ABS
52
Built-in noise reduction sponge
1
P18
53
Air pump motor stand
1
PA66+30%GF
54
Motor cushion
1
silicon gel
55
Bubble motor
1
AC230V/600W
56
Motor cushion
1
silicon gel
57
Motor seal 1
silicon gel
45-55A
58-60
Top cover of motor
1
ABS etc
61
Checking valve
1
ABS+PVC
62
rotary switch
1
ABS
63
Knob ring
1
ABS
64
The lid switch
1
ABS
65
Screw M5*15
1
SUS304
66
The mainboard under cover
1
ABS
67
The mainboard upper cover
1
ABS
68
Power board
1
fiberglass
，
94V0 t1.6
69
Ground terminal
1
SUS304
70
Line pressing gate
1
PA6
71
Plug+PRCD+power cable
H07BQ-F,3*1.0MM2
1
Rubber+copper+PC
72
Screw ST3*15
4
73
Screw ST3*10
56
45#,
74
Screw ST4*18
35
SPCC,
75
Screw ST3*8
14
45#,
76
Panel sticker
1
PET
，
77
Round button in the panel
4
transparent silicone 45-55A
78
Semicircle button in the panel
2
transparent silicone 45-55A
79
Panel front shell
1
Golden ABS
80
PCBA in the display
1
fiberglass
，
94V0 t1.6
81
Sealed ring in the display
1
Black silicone 45-55A
82
4-pin signal cord
1
PVC+copper
83
Under shell of the panel
1
Black ABS
