2019-2020 Delight Service Manual
Visit our website at: www.the-mspa.com
- 21 -
9、Take down the filter pump and disassemble the
connection pin-cable from filter pump to transformer
10
、
Loosen the 4 screws and take out the original
transformer. Assemble the new transformer into the
control box in reverse order.
。
4.6 How to replace filter pump (B9301262)
1、Take out the control box；
2
、
Loosen four screws (ST4*60) from the bottom of the
cabinet
3、Loosen five screws (ST4*15) from the rear cover
of the cabinet; Loosen two screws (ST4*15) from the
base of the cabinet
4、Take out the internal cabinet and power board；
7、 Loosen 4 screws from the filter pump
6
、
Loosen the plastic connection nut from inlet and filter
pump
；
