26441 3/18 | 85-000862_INST_C
MINIAC SPEED & CADENCE SENSOR INSTRUCTIONS
6400 WEST 105TH STREET // BLOOMINGTON, MN 55438 // 1-855-883-6563 // WWW.MSWBIKE.COM
5. Use two zip ties to tighten the sensor to the chainstay, and snip off the
excess length.
6. Make any final adjustments to the sensor arm to achieve the required
distance between it and the wheel magnet, and tighten the knurled dial.
PAIRING THE MSW MINIAC DOUBLE WIRELESS
COMPUTER WITH THE SENSOR
(For pairing with other compatible cycling computers reference manufacturer’s
instructions for that computer.)
In any mode, press the M and C buttons, and hold for six seconds, and then
press C button. The computer will search for 30 seconds. If it is paired, it will
show the ID and go back to the original page in 5 seconds. If it is not paired,
check that the sensor and magnets are aligned; also check the battery (fig. 5).
Test to make sure that the magnets are activating the sensor, and the
computer head unit is registering the magnets as they pass the sensor.
MAINTENANCE
Check the position of sensor and magnet periodically. Rust or corrosion on the
magnet may cause malfunction. The gap between magnet and sensor cannot
exceed 3mm.
BATTERY REPLACEMENT
A red light on the sensor will appear when its battery is running low. Unscrew
the back cover. The (+) side should be facing up. Gently remove the battery and
replace it with a new battery model CR2032.
BATTERY WARNINGS
A coin-cell, lithium-ion battery is used in this device. If these guidelines are not
followed, batteries may experience a shortened lifespan or may present a risk
of damage to the device, fire, chemical burn, electrolyte leak, and/or injury.
• Do not leave the device exposed to a heat source or in a high-temperature
location, such as in the sun in an unattended vehicle.
To prevent the possibility of damage, remove the device from the vehicle
or store it out of direct sunlight, such as in the glove box
• Do not disassemble, modify, remanufacture, puncture or damage the device
or batteries
• Do not immerse or expose the device or batteries to water or other liquids,
fire, explosion, or other hazard
• Do not use a sharp object to remove the batteries
• Replaceable coin-cell batteries may contain perchlorate material. Special
handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate
• Only replace batteries with correct replacement batteries. Using other
batteries presents a risk of fire or explosion
• Do not operate the device outside of the temperature ranges specified
in these instructions
• Contact your local waste disposal department to dispose of batteries
in accordance with applicable local laws and regulations
WARNING:
• KEEP BATTERIES AWAY FROM CHILDREN
• NEVER PUT BATTERIES IN MOUTH. Swallowing can lead to chemical burns,
perforation of soft tissue, and death. Severe burns can occur within two
hours of ingestion. Seek medical attention immediately
LIMITED 2-YEAR WARRANTY
MSW warrants this new MSW product against defects in materials and
workmanship for two (2) years from the original date of retail purchase
by the consumer. This limited warranty is expressly limited to the repair
or replacement of the original product, at the option of MSW, and is the
sole remedy of the warranty. This limited warranty applies only to the
original purchaser of the MSW product and is not transferable.
In no event shall MSW be liable for any loss, inconvenience or damage,
whether direct, incidental or consequential or otherwise resulting from breach
of any express or implied warranty or condition of merchantability, fitness for
a particular purpose, or otherwise with respect to this product except as set
forth herein. This warranty gives the consumer specific legal rights, and those
rights and other rights may vary from state to state.
This warranty does not cover the following:
• Damage due to improper assembly or follow-up maintenance or lack
of skill, competence or experience of the end user
• Products that have been modified, neglected, used in competition or for
commercial purposes, misused or abused, involved in accidents or anything
other than normal use
• Damage or deterioration to the surface finish, aesthetics or appearance
of the MSW product
• Normal wear and tear
• Labor required to remove and/or refit and re-adjust the product within
the bicycle assembly
• Installation of components, parts, or accessories not originally intended
use with or compatible with MSW products
TO THE EXTENT NOT PROHIBITED BY LAW, THESE WARRANTIES ARE
EXCLUSIVE AND THERE ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES
OR CONDITIONS INCLUDING WARRANTIES OR CONDITIONS OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
WARRANTY PROCESS
If you and your shop think your MSW product is worthy of a warranty
inspection, please return the product to the original place of purchase,
accompanied by a sales receipt.
For complete warranty information, visit www.mswbike.com/safety/warranty.
Bracket
Nylo n
Ties
Rubber
Bracket
Cycle Computer
Rubber Pad
Bracket
Cycle Computer
1–3mm
1–3mm
Spoke
Chainstay
(non-driveside)
Rear
Wheel
Front
Wheel
Cadence Sensor
Speed Sensor
Zip Tie
Cadence Magnet
Crank
Pedal
Cadence Sensor
1–3mm
Time Average Speed Maximum Speed Distance
Odometer Calorie Consumption
Average Cadence Maximum Cadence Trip Cadence
Unit
Tire size
Time
Time
Gender / Weight
ODO
Temperature
Gender / Weight
M
(
MODE
)
: Next option
C: Next setting
[
SET
]
: Change the value
Temperature °C/°F
H1 (Male)
H2 (Female)
WS: 0100–2999mm
KM/H+Kg+KM
M/H+Lb+KM
12H/24H
[
SET
]
Weight: 20–150Kg
44–330 lb
3 seconds
Searching for 30 seconds
Press and hold mode
key for 3 seconds
After 5 seconds of receiving
code from the sensor
PAIRED NOT PAIRED
C BUTTON
MODE BUTTON
M M
C
M/CM/C
M/C
M/CM/C
M
M
M
MMM
[
SET
][
SET
]
C
M/C Save and Exit
Hour (1–24)
Minute (0–59)
Second (0–59)
>M
[
SET
]
C C
C
C
PRESS
Not paired:
• Check sensor alignment
• Check battery
Figure 5
