Removing the Side Pads
There are 3 pressure clips that hold the side pads in place.
1
Lift the side pad, separating it from the shell, in order to drop
the pressure clips.
2
Hold the side pad in place and gently pull the chin strap.
Installation of the side pads
1
Pass the strap through the opening in the pad at cheek level.
2
Fully align and slide the plastic pad plate between the shell
and the EPS.
3
Attach the 3 male clips on the side pad to the 3 female clips
xed inside the shell and press.
1
1 2
3
2
21
NECK BRACE DISASSEMBLY
