Stinger 2
24
There are 3 snaps that hold the side pads in place.
1
Gently lift the side pad away from the shell in order to release the snaps.
2
Grasp the side pad from its centre and gently pull on the chinstrap.
1
Pull on the rear part of the liner until the two snaps holding it are released.
2
Pull the front part of the liner until the tabs are completely separated from the shell.
Once both steps are completed, the liner will be completely detached from the helmet.
1
1
2
2
