Thunder 4 SV
31
1
Unscrew the two Allen key No. 2 screws to release the spoiler.
2
Push to detach it from
the helmet.
1 2
1
Remove the screws from the cover in order to remove it and insert UCS systems into
the housing.
2
Once inserted, the screws should be placed back in their original position.
*UCS, Universal Communication System.
1 2
