MTD 136 User Manual

17
REF.
NO. PART NO. DESCRIPTION
1 749-1042A Upper Handle
2 749-1312 Lower Handle
3 720-0369 Handle Plug
4 710-1718 Handle Bolt
5 736-0649 Lock Washer
6 712-0690 Hex Nut
7 710-1757 Screw
8 725-1941 Motor / Blade Control Switch
9 731-2427 Cord Insulator
10 731-2421-0638 Mower Housing (Incl. Ref# 39-41)
11 731-2088A-0637 Electric Motor Cover
12 731-2224 Air Guide Pot
13 724-0310 Electric Motor
14 710-1756 Screw
15 631-0148 Blade Hub Assembly
16 742-0804 Cutting Blade
17 731-1961 Lock Washer
18 624-0077 Blade Bolt
19 731-1971A-0637 Rear Discharge Door
20 747-1072 Rod
21 732-0912 Spring
22 736-0697 Washer
23 736-0698 Lock Washer
24 710-1350 Screw
25 731-1805-0638 Cap
26 782-0609 Holder Plate
27 734-1884-0637 Rear Wheel
28 734-1885-0637 Front Wheel
29 720-0343-0637 Rear Wheel Cap
30 720-0342-0637 Front Wheel Cap
31 738-1031 Axle Bolt
32 731-2402 Rear Trailing Shield
33 710-1758 Screw
34 747-1010 Guide Rod
35 726-0368-0637 Cable Clamp
37 731-1968-0637 Grass Bag
38 731-2426-0637 Grass Bag Cover
39 782-9095-0638 Protection Plate
40 736-0766 Washer
41 728-0286 Rivet
