MTD 13AB606H730 - Page 43

ModelSeries606
REF.
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
PART
NO.
17116
17258D
618-0240A
618-04134A
683-0254B
683-04104A
710-0344
710-0514
710-0528
710-0599
710-0751
710-0778
710-0805
710-1260A
710-3180
711-04069
711-0993
711-1554
712-0206
712-04063
712-04064
712-04065
712-0417A
712-0431
712-0641
712-3006
712-3010
712-3083
714-0470
717-04074
726-0233
DESCRIPTION
Brake Assembly, Deck
RH Belt Cover, Deck 46"
Spindle Assembly, 5.00 Dia.
Spindle Ass'y, Double Pulley
Hanger Bracket Assembly
Deck Weldment
Screw, 3/8-16, 1.50, Gr5
Screw, 3/8-16, 1.00, Gr5
Screw, 5/16-18, 1.25, Gr5
Screw, 1/4-20, 0.500
Screw, 1/4-20, .620, Gr5
Screw, 1/4-20, 1.500
Screw, 5/16-18, 1.50, Gr5
Screw, Ld, 5/16-18, 0.750
Screw, 5/16-18, 1.75, Gr5
Pin, Grasscatcher, 1/4-20
REF. PART
NO. NO.
32 732-0306A
33 732-0429A
34 732-0594A
35 732-1165
36 734-0973
37 736-0119
38 736-0225
39 736-0270
40 736-0418A
41 736-3084
42 731-1032B
43 738-0347
44 738-0373
45 738-04146
46 742-0611A
47 742-0612A
DESCRIPTION
Spring, Compression, .531 OD x 1.75
Spring, Extension, .50 Dia x 3.97
Spring, Extension, .91 Dia x 7.33
Spring, Extension, .50 Dia x 5.0
Wheel, Deck 5.0 x 1.38
Washer, Lock, 5/16
Washer, Lock, 5/8
Washer, Bell, .265 x.75 x .062
Washer, Flat, .34 x 2.25 x. 10
Washer, Flat, .51 x 1.12 x .06
Chute Assembly
Spacer, Shoulder, .625 ID x .169
Spacer, Shoulder, .498 x 1.53, 3/8-16
Plug, Screw, M16 x 1.5
Blade, 16.28", Star 3-in-One
Blade, 14.88", Star 3-in-One
Belt
Pin,
Nut,
Nut,
Nut,
Nut,
Nut,
Nut,
Nut,
Nut,
Nut,
Nut,
Pin, Cot, 1/8x 1.25
Adjustment Gear, Deck
Nut, Push, .25 ID x .50 OD
Guard Pin 1/4 Diax 1.43
1/4-20, 3/8 x 2.0
Hex, 1/2-13, Gr5
Flange Lock, 5/16-18, GrF, Nylon
Flange Lock, 1/4-20, GrF, Nylon
Flange Lock, 3/8-16, GrF, Nylon
Flange, 5/8-18
Flange Lock, 3/8-16, GrF
Hex, M16-1.5
Hex, 1/4-20, Gr5
Hex, 5/16-18, Gr5
Hex Lock, 1/2-13, Gr8, Nylon
48 746-1107
49 747-1116
50 747-1130B
51 748-0234
52 750-0566A
53 750-1320
54 754-0349
55 754-04064
56 756-04129
57 783-1348B
58 783-0141
59 783-0142
60 783-04641
61 783-1025
Cable, 12.00"
Rod, Deck Release
Rod, Deck
Shoulder Spacer
Spacer, .260 x .372 x 1.030
Spacer, .375 x .63 x .595
Belt, V-Type, Poly
Belt, V-Type
Pulley, Idler, 4.25" Dia.
Belt Cover, LH
Deck Skirt, Center
Deck Skirt, RH
Bracket, Idler
Stop, Chute
IMPORTANT:For a proper
working machine, use
Factory Approved Parts.
V-belts are designed to
engage and disengage
safely. A substitute (non
OEM) V-belt can be
dangerous by not
disengaging completely.
NOTE: Tractor features vary by model. NOT aft parts listed above and pictured on the previous page are standard equipment.
43
