MTD 19A30002000 User Manual

19se c t i O n 7 — pa r t s li s t
Ref. Part Number Description
1. 631-04291 Upper Chute Assembly
2. 631-04292 Double Bagger Cover Assembly
3. 731-06497 Upper Chute Support
4. 731-06504 Bagger Cover Screen
5. 710-0276 Carriage Screw, 5/16-18 x 1.00”
6. 710-3008 Hex Head Screw, 5/16-18 x .75”
7. 711- 0 30 9A Clevis Pin, .62” Dia.
8. 711- 0 4 0 6 9 Grass-catcher Pin, 1/4-20
9. 711-05063 Clevis Pin, 5/16 x .75 Lg.
10. 712-04063 Flange Lock Nut, 5/16-18
11. 712-04064 Flange Lock Nut, 1/4-20
12. 714 - 0117 Internal Cotter Pin, .148 x 3.00
13. 714-04040 Bow-Tie Cotter Pin, 72
14. 723-04008A Chute Strap, 6.00 Lg.
15. 726-3046 Ratchet Clip, .250
16. 731-04153A Discharge Chute Elbow, 38”/42”
17. 731-06610 Bagger Chute Adapter, 7 In.
18. 736-0204 Flat Washer, .344 x .62 x .033
19. 783-05887 Universal Bracket Support, RT-99/
20. 664-04096 Grass-bag Assembly
21. 683-04461 Double Bag Support Assembly
22. 683-04519 Vertical Support Bracket
23. 711- 0 4 98 8 Cover Hinge Pin
24. 735-0246A End Plug
25. 710-04484 Tap Screw, 5/16-18 x .750
26. 710-0332 Clevis Pin, .50 x .78 Lg.
27. 712-04065 Flange Lock Nut, 3/8-16
28. 714-0145 Click Pin, .092 x 1.64 Lg.
29. 738-04267 Shoulder Screw, .625 x .412
30. 783-05889 Mounting Bracket, RH
31. 783-05890 Mounting Bracket, LH
32. 689-00101 Hitch Bracket Assembly
33. 789-00052 Hitch Bracket, RH
34. 789-00053 Rear Attachment Bracket
35. 789-00054 Hitch Bracket, LH
