17
Ref. Part Number Description
1. 931-04291 Upper Chute Assembly
2. 931-04298 Triple Bagger Cover Assembly
3. 731-06497 Upper Chute Support
4. 731-06504 Bagger Cover Screen
5. 710-0276 Carriage Screw, 5/16-18 x 1.00”
6. 710-3008 Hex Head Screw, 5/16-18 x .75”
7. 711- 0309A Clevis Pin, .62” Dia.
8. 964-04096 Grass-bag Assembly
9. 683-04498 Triple Bag Support Assembly
10. 683-04519 Vertical Support Bracket
11. 711-05079 Cover Hinge Pin
12. 712- 04063 Flange Lock Nut, 5/16-18
13. 735-0246A End Plug
14. 631-04300 Discharge Chute Elbow, 50/54” Deck
15. 683-0617A-0637 Chute Stop-Bracket
16. N/A* Hitch Bracket, RH
17. N/A* Universal Rear Attachment Bracket
18. N/A* Hitch Bracket, LH
19. 703-05783-0637 Deck Bae, 50”
20. 703-06018A-0637 Deck Bae, 54”
21. 710 -3015 Tap Screw, 1/4 - 20 x .750 (50” Deck)
710-04484 Tap Screw, 5/16-18 x .750 (54” Deck)
22. 712-04064 Flange Lock Nut, 1/4 - 20 (50” Deck)
23. 710-3168 Carriage Screw, 3/8 - 16 x 1.00”
24. 712- 04065 Flange Lock Nut, 3/8 - 16
25. 714 - 0117 Internal Cotter Pin, .148 x 3.00
26. 726-3046 Ratchet Clip, .250
27. 731- 0 6 611 Bagger Chute Adapter, 7 In.
28. 742-04056C-0637 Blade, 17.90 Lg., Star Bagging
29. 942-0679 Blade, 18.50 Lg., High Lift
30. 783-05887-0637 Universal Bracket Support, RT-99/LT-5
31. 723-0476 Chute Strap
32. 710-04484 Tap Screw, 5/16-18 x .750 (54” Deck)
33. 689-00101 Mounting Bracket Kit (Incl. Ref. 16-18)
34. 783-06418 Discharge Chute Plate
*Order Reference No. 33
