Illustrated
Parts List
Model 390
Series
Ref. Part No. Part Description
1 712-0392 Hex L-Stop nut 1/4-28
2 736-3020 Flat Wash.266” I.D. x.625” O.D.
3 710-0599 Hex Washer TT-Tap Scr. 1/4-20 x.5”
4 711-0920 Belt Cover Bolt
5 712-04063 Hex Flange Top L-Nut 5/16-18
6 710-0723 Hex Hd. Scr. 3/8-16 x 1.25” Lg.
7 756-0313 Flat Idler Pulley 2.12” O.D.
8 786-0149 Idler Belt Keeper
9 786-0144 Idler Bracket
10 712-0266 Hex Cent. Jam Nut 3/8-16 Thd.
11 786-0057 Belt Cover
13 786-0043A Tine Shield
14 710-3008 Hex Hd. Cap Scr. 5/16-18 x.75” Lg
16 686-0091 Chain Case Assembly Complete
17 686-0106 Outer Disc Plate Assembly
18 714-0149B Internal Cotter Pin
19 711-0415 Clevis Pin
20 642-0023 Outer Tine Assembly L.H.
642-0024 Outer Tine Assembly R.H.
21 642-0003 Inner Tine Assembly L.H.
642-0002 Inner Tine Assembly R.H.
22 746-0918 Forward Clutch Cable
23 746-0953 Reverse Clutch Cable
24 756-0585 Fl-Pulley 6” Dia.
25 750-0892 Spacer.64” Dia. x 2.4” Lg.
Ref. Part No. Part Description
26 748-0350 Pulley Mounting Adapter
27 736-0112 Bell-Wash.525” I.D. x 1.5” O.D.
28 712-3029 Hex Jam Nut 1/2-20 Thd.
29 732-0697 Return Spring
30 786-0040B Reverse Bracket
31 736-0119 Lock Washer 5/16
32 710-0237 Hex Bolt 5/16-24 x.625”
33 756-0971 Engine Inner Half Pulley
34 756-0600 Reverse Engine Pulley
35 736-0452 Bell Washer.396” I.D. x 1/14” O.D.
36 710-1093 Hex Bolt 3/8-24 x 1.00”
38 686-0013 Reverse Arm Assembly
42 786-0041 Reverse Belt Keeper
43 710-0502A Hex L-Wash. TT-Tap 3/8-16 x 1.25”
44 786-0145A Engine Plate
45 786-0053 Tine Shield Bracket
46 736-0171 L-Wash. 7/16” I.D.
47 712-0240 Hex Nut 7/16-20 Thd.
48 754-0428 V-Belt (Forward) 1/2 x 41.9”
49 754-0429 V-Belt (Reverse) 3/8 x 45.68”
50 738-0102 Shld. Screw.498 x 1.445
51 738-0930 Shld. Screw.560 x.165
52 710-0805 Screw 5/16-18 x 1.50 †††
53 712-3010 Hex Nut 5/16-18 †††
54 736-0242 Bell Washer †††
††† Honda Engine
To order replacement
parts, contact
1 (800) 800-7310
or visit
www.mtdproducts.com
