MTD 390 Shown - Page 21

21
Model 390
REF.
NO.
PART NO. DESCRIPTION
1 712-0442 Acorn Lock Nut 1/4-20
2 736-3020 Flat Washer .271” I.D. x .630” O.D.
3 720-0270A Reverse Handle Grip
4 731-1600 Handle Cover w/o throttle
5 710-0779A Truss Mach. Scr. #10 x 1/2” Lg.
6 720-0274 Grip-Handle
7 712-0287 Hex Nut 1/4-20 Gr.2
8 726-0135 Cap Speed Nut
9 686-0083 Clutch Handle Assembly
10 720-0269 Grip-Clutch
11 710-0641 Hex Bolt 1/4-20 x 2.25” Lg. Gr.5
12 731-1645A Clutch Handle Holder
13 736-0140 Flat Washer .385” I.D. x .62” O.D.
14 686-0014A Reverse Handle Ass’y
15 736-0264 Flat Washer .344” I.D. x .62” O.D.
16 649-0039 Handle Assembly Comp. †
649-0022A Handle Assembly Comp. ††
17 647-0042 Adjustment Crank †
18 726-0211 U Nut 5/16-18 †
19 749-1101 Handle Brace †
20 736-0921 Lock Washer 1/2 †
21 710-3194 Hex Bolt 1/2-20 Gr. 5 †
22 786-0005 Depth Bar
23 714-0149B Cotter Pin
24 712-3004A Hex Flange L-Nut 5/16-18 Thd. Gr.5
25 786-0003 Tail Piece Bracket (L.H.)
26 786-0004 Tail Piece Bracket (R.H.)
27 711-0415 Clevis Pin
28 710-0805 Hex Bolt 5/16-18 x 1.5” Lg.
29 710-0189 Hex Bolt 5/16-18 x 3” Lg.
30 736-0242 Wash. Bell. .340” I.D. x .872” O.D.
31 711-1036 Spec. Hex Nut
32 736-0119 L-Wash. 5/16” I.D.
33 710-3008 Hex Bolt 5/16-18 Gr. 5
34 786-0129 Cable Guide Bracket
35 710-0604 Hex Wash. Hd. TT-Tap Scr. 5/16-18 x
.62” Lg.
36 710-0602 Hex Wash. Hd. TT-Tap Scr.
37 738-0934 Shdl. Bolt 5/16-18
38 786-0138 Frame (R.H.)
39 786-0139 Frame (L.H.)
40 736-0171 Lock Washer 7/16
41 712-0240 Jam Nut 7/16-20 Gr. 2
42 710-0176 Hex Bolt 5/16-18 x 2.75” Lg.
43 712-0429 Hex Nyloc Nut 5/16-18 Thd.
44 711-0415 Clevis Pin
45 714-0149B Cotter Pin
46 686-0081A Wheel Hanger Brkt. Assy
47 734-1566 Wheel Ass’y 8” x 1.75”
48 738-0929 Shoulder Screw .496 I.D. x 1.445 O.D.
49 750-0890 Spacer
50 710-1236 Carr. Bolt 5/16-18 x 1 ††
51 749-0915A Engine Tube Brace (Std. B&S)
749-1082 Engine Tube Brace (Tec.)
52 712-3004A Hex Flange L-Nut 5/16-18 Thd.
(Gr. 5) ††
53 786-0159 Engine Brkt. (Std. B&S)
54 736-0242 Bell. Wash. .34” I.D. ††
55 720-0195 Hand Knob††
REF.
NO.
PART NO. DESCRIPTION
† Briggs & Stratton Intek Engine
†† Standard Briggs & Stratton and Tec. Engine
