MTD 500 - Page 27

Models 500, 501, 510 and 511
PARTS LIST FOR MODELS 500, 501, 510 AND 511 RIDING MOWERS
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
1
731-0220
Steering Wheel Cap
31 712-0206
Hex Nut 1/2-13 Thd.*
2 712-0267 Hex Nut 5/16-18 Thd.*
32
736-0105
Bell-Wash. .385" I.D. x .88"
3
736-0242 Bell-Wash. .345" I.D. x .88"
O.D.
O.D.
33
712-0241
Hex Nut 3/8-24 Thd.*
4 731-0219
Steering Wheel Ass’y-
34 736-0119
L-Wash. 5/16" I.D.*
5
738-0537 Steering Shaft
35
712-0267
Hex Nut 5/16-18 Thd.*
6
750-0568
Steering Tube Spacer
38 723-0156
Ball Joint Ass’y. 3/8-24 Thd.
(Chrome)
39
714-0115 Cotter Pin 1/8" Dia. x 1.0"
7
731-0651
Steering Tube Spacer
Lg.
8 736-0187
Fl-Wash. .640" I.D. X 1.25"
40 747-0417
steering Tie Rod
O.D.
41
15616
Front Axle Ass’y.—R.H.
9 741-0225
Hex Flange Bearing
15617
Front Axle Ass’y.—L.H. (Not
10 15613
Pivot Bar Bracket
Shown)
11
710-0118
Hex Bolt 5/16-18 x .75" Lg.‘
42 741-0313
Flange Bearing .632" I.D.
12 15614 Steering Gear Support Brkt.
43
★ *
Front Wheel Ass’y. Comp.
13 710-0776
Hex Wash. Hd. AB-Tap Scr.
44
* 4r
Front Wheel Rim Only
1/4 X .62" Lg.
46 714-0470
Cotter Pin 1/8" Dia. x 1.25"
14
15608
Steering Gear Cover
Lg.*
15 741-0225
Hex Flange Bearing
47
714-0115
Cotter Pin 1/8" Dia. x 1.00"
16 736-0285 Fl-Wash. .640" I.D. x 1.62"
Lg.*
O.D.
48 736-0300
Fl-Wash. .385" I.D. X .87"
17
738-0541 Shoulder Spacer .622 Dia. x
O.D.
.218
49 736-0156
Fl-Wash. .635" I.D. x 1.12"
18
748-0290
Steering Pinion Gear
O.D.
19 736-0320 Fl-Wash. .385" I.D. x 1.38"
50
741-0225
Hex Flange Bearing
O.D.
52
736-0156
Fl-Wash. .635" I.D. x 1.12"
20 710-0502
Hex Wash. Hd. Self-Tap Scr.
O.D.
3/8-16 X 1.25" Lg.
53 15610
Pivot Bar Ass’y.
21 736-0242 Bell-Wash. .345" I.D. x .88"
54
726-0159
Speed Nut 5/8" I.D.
O.D.
55 15613
Pivot Bar Bracket
22 712-0123 Hex Nut 5/16-24 Thd.*
56 15694
Bracket Reinforcement—
23 710-0191
Hex Bolt 3/8-24 x 1.25" Lg.
R.H.
(Grade 5)
57
710-0776
Hex Wash. Hd. AB-Tap Scr.
24 736-0320 Fl-Wash. .385" I.D. x 1.38"
1/4 X .62" Lg.
O.D.
59 15562
Clutch-Brake Pedal Ass’y.
25 712-0241 Hex Nut 3/8-24 Thd.*
60
710-0118
Hex Bolt 5/16-18 x .75" La.*
26 736-0169
L-Wash. 3/8" I.D.*
61
15699
Bracket Reinforcement—L.H.
27 717-0472 Steering Gear Segment
62
710-0118
Hex Bolt 5/16-18 X .75" Lg.*
28
738-0541 Shoulder Spacer .622" Dia. x
63 731-0484
Plastic Hub Cap
.218
69 16042
Steering Shaft Ass’y.
29
710-0689
Hex Bolt (Nylon) Vz-IS x .75"
70 736-0187
Fl-Wash. .62" I.D. x 1.50"
Lg-
O.D.
30 736-0160 Fl-Wash. .530" I.D. x .930"
71
750-0532
Spacer (Plastic)
O.D.
(462—Red Flake)
*For faster service obtain standard nuts, bolts and washers
locally. If these items cannot be obtained locally, order by
part number and size as shown on parts list.
When ordering parts, if color or finish is important use the ap¬
propriate color code shown above, (e.g. Flake Finish—
11836 (462).) y ». -? — •
Description
11 X 4.0—"^art No.
10.5 X 3.5—Part No.
Wheel Assembly Comp.
734-1044
734-1000
Tire Only
734-0770
Rim Only
734-1042
Bearing
741-0313
741-0313
Air Valve
734-0255
-
Grease Fitting
737-0146
737-0146
