10
SECTION 4: OPERATION
Know the Controls
Read this owner’s manual and safety rules before operating your lawn mower. Compare figure below with your lawn
tractor to learn about the loction and purpose of various controls and adjustments. Save this manual for future
reference. It is very important to follow the instructions and operate the controls properly.
Figure 5
NOTE: Any reference in this manual to the RIGHT or LEFT side of the tractor is observed from operator’s position.
A PTO (Blade Engage) Lever/Knob G Throttle/Choke Control Lever
B Choke Control Knob (if equipped) H Cruise Control Button
C Parking Brake Button I Ignition Switch
D Shift Lever J Brake Pedal
E Cup Holder K Drive Pedal
F Systems Indicator Monitor/ Hour Meter M Deck Lift Lever
I
B
A
H
C
D
E
K
J
1
/
1
0
+
P
G
M
F
Steering Wheel not shown for clarity.
