25
Models 650 & 652
REF.
NO.
PART
NO. DESCRIPTION
1 710-3008 Hex Screw, 5/16-18 x .75
2 710-0642 Self-tapping Screw, 1/4-20 x .75
3 712-0185 U-type Speed Nut, 1/4-20
4 712-0429 Hex Lock Nut, Nylon, 5/16-18
5 712-3027 Flange Lock Nut, 1/4-20
6 726-0201 Speed Nut, .3125
7 726-04012 Push-on Nut, .25
8 731-1601 Lens, Black
9 738-04015 Shoulder Screw, 5/16-18 x .625
10 738-0952A Shoulder Screw, 1/4-20 x .375 /.125
11 749-0722C Grille Support Rod
12 783-0250A Hood w/ Louvers
13 629-0469B Headlamp Harness Assembly
14 783-0366 RH Side Panel (Insert)
15 783-0367 LH Side Panel (Insert)
16 731-04612 Grille
17 725-1396 Ignition Switch, 6-pin
18 725-0201 Keys (pair)
19 710-0751 Hex Screw, 1/4-20 x .620
20 725-0963 Headlamp, 12V
21 725-1651 Headlamp Socket
22 17632D Support Bracket
23 710-0599 Self-tapping Screw, 1/4-20 x .5
24 710-0607 Self-tapping Screw, 5/16-18 x .5
25 710-0788 Self-tapping Screw, 1/4-20 x 1.0
26 726-3054 U-type Speed Nut, 1/4-20
27 731-04179 Dash Panel
28 746-04020A Throttle / Choke Control, 18.5”
29 736-3090 Flat Washer, .260 x .720 x .060
30 726-0209 Cable Tie, 30.66
31 751-0555B Fuel Tank, 1.5 gal.
32 751-0603 Fuel Tank Cap
33 728-0162 Rivet, 1/4”
34 712-0324 Hex Lock Nut, Nylon, 1/4-20
35 736-3078 Flat Washer, .344 x 1.0 x .063
36 731-1503A Lens
37 783-0156B Grille
38 731-04387 Steering Bellow
NOTE: Tractor features vary by model. NOT all parts listed above and pictured on the previous page are standard equipment.
