MTD 652 - Page 29

29
Models 650 & 652
REF.
NO.
PART
NO. DESCRIPTION
1 17239C Seat Lift Bracket
2 17950A RH Pivot Support Bracket, Seat
3 17951A LH Pivot Support Bracket, Seat
4 710-0227 Self-tapping Screw, #8-18 x .50
5 710-0726 Self-tapping Screw, 5/16-12 x .75
6 712-0429 Hex Lock Nut, 5/16-18
7 725-1303 Outer Seat Spring Switch
8 725-1439 Inner Seat Spring Switch
9 726-0278 Insulator Plate Boss
10 726-0279 Insulator Plate
11 732-0581B Extension Spring, .75 x 5.31
12 738-0296 Shoulder Screw, .437 x .286
13 17770H Running Board
14 17870C Fender
15 710-0751 Hex Screw, 1/4-20 x .620
16 710-1208 Self-tapping Screw, 5/16-18 x 3.5
17 710-3008 Hex Screw, 5/16-18 x .75
18 712-0429 Nylon Lock Nut, 5/16-18
19 712-3027 Flange Lock Nut, 1/4-20
20 732-04038 Compression Spring, 1.314 x 1.8
21 750-04212 Spacer
22 783-04139A LH Running Board
23 710-0599 Self-tapping Screw, 1/4-20 x .5
24 725-1643 Spring Switch, Long
25 726-0320 Insulator Nut Plate
26 726-3054 U-Clip Nut, 1/4-20
27 783-04429 Shift Cover Panel, 5-speed
28 710-0870 Screw, 3/8-16 x .625
29 738-04012 Shoulder Screw, .625 x .175, 3/8-16
30 783-04081A Seat Pivot Bracket, Manual Adjust
31 710-0703 Carriage Screw, 1/4-20 x .75
32 761-0168B Blade Spindle Brake Assembly
33 757-04021 Low Back Seat, Black
34 710-0870 Screw, 3/8-16 x .625
35 736-3008 Flat Washer, .344 x .750 x .120
NOTE: Tractor features vary by model. NOT all parts listed above and pictured on the previous page are standard equipment.
